Description

• Powerful 4HP (6.5HP Peak) Continuous Duty Motor
• Easy Drum Pressure Adjustment
  • 5 Settings (50, 60, 70, 80, 90 lb)
  • Tune your floor belt sander for specific job site conditions or personal preference
• Enhanced Chassis Suspension System
  • A balanced system of compression and extension springs provides superior stability, helping to eliminate side cutting, wave, and chatter on damaged and uneven floors
• Dual Mode Feathering Handle
• Drum and Top Roller System
  • Advanced engineering provides an aggressive cut while requiring minimal operator maintenance.
  • “V” Crown, dynamically balanced upper roller
  • Precision balanced drum with cooling slots
  • Simple, fast, precise paper alignment
  • Vented paper door facilitates dust collection, reduces buildup on upper roller
• Laser Guide for Enhanced Sight Lines
• Monitor Critical Functions
  • Digital Run-Time Meter
  • Digital Volt Meter
  • On-Board Circuit Breaker
• Onboard Transport Dolly
  • Can be left on machine without fear of rubbing the wall
  • Remove or attach in seconds
• Multi-Use Transport Handle
  • Carry the motor or carry the frame
• Tool-Free Quick Release Motor Mount
• Optional Stair Climber Dolly
• Control Center with Intuitive Power Switch and USB Charge Port
• Optional Adjustable Height Handle: Adjustable height handle provides ergonomic comfort to reduce fatigue for operators of all sizes.
  • 4 Settings
  • Lowest Setting: 33.6″ from floor
  • Highest setting: 37.9″ from floor
• Dust-Free Bag Connection
  • Check valve connector prevents dust release when bag is disconnected
  • Also accepts drawstring bag or vacuum hose
  • Dust tube rotates freely or can be locked in place
• Dual Poly-V Belts
  • Reduced vibration
  • No need to loosen belt tension in between jobs
• Tool-Free Belt Tension Release
• Bright White LED Work Light
• Reduced Noise Level
• Onboard Tool Kit

Specifications:

Motor: 6.5 hp peak / 4 hp continuous
208 – 230 V / 60 Hz 240 V / 50 Hz (3 hp / 2.2 kW)
Drum Size: 8 in
Drum Pressure (5 Positions): 50, 60, 70, 80, 90 lb
Wheels: Molded urethane wheels – 4 in
Caster – 3 in split-type
Power Cable: 50 ft. gray, non-marking, rubber
Transport: Patented Dolly Transport System
Dimensions: 35 x 14 x 37 in
Weight: 200 lb
Shipping Weight: 290 lb
Warranty: 1 Year Parts & Labor
